STB-UMT-S265-mini

وصف قصير

STB-UMT-S265-mini is set-top box (STB, receiver, television decoder) which works in DVB-S and DVB-S2 standards and supports MPEG-2/MPEG-4/H.264/HEVC/H.265 codecs, also has CA smart card slot.

- +

طلب معدات مخصصة HEAD-END

    • وصف
    • التحميلات
    DVB-S2 Specification
    Tuner
    InputFrequency Range 950MHz to 2150MHz
    Input Inpedance 75Ohms unbalanced
    Signal Input Level -65 ~ -25dBm
    Symbol Rate 2-45Mbps
    LNB Power 13/18V,Max 350mA
    47-862 MHz
    Demodulation
    Demodulator QPSK/8PSK
    FEC Modes Rate 1/2,2/3,3/4,5/6,7/8,8/9,9/10
    System Resources
    SDRAM memory 1Gbit    DDR3
    FLASH memory 64Mbit  FLASH
    Video Decoder
    Standard ISO/IEC 13818-2 and ISO/IEC 14496-10
    Transport stream ISO/IEC 13818-1
    Video decoding HEVC/H.265,MPEG-4 H.264/AVC SD/HD,MPEG-2 SD/HD (MP@ML and MP@HL),
    JPEG,BMP,PNG, Motion JPEG
    AVI, VOB, MOV, MKV
    Video Resolution 480i, 480p, 576i, 576p, 720p, 1080i, 1080p
    Aspect ratio 4:3, 16:9，Auto
    Audio Decoder
    Standard MPEG-1 Layer I & II, MPEG-2 Layer II, AAC, MP3, HE-AAC,AC-3(optional), E-AC-3(optional)
    Sample rate 32, 44.1, 48
    Subtitles & Teletext
    Subtitle DVB Subtitle
    Rear Panel
    HDMI HDMI version 1.3
    LNB Input IEC169-2 Female
    USB 2
    RS232 1
    CVBS & Audio R/L RCA(1 ports)
    IR Port IR External LED Display
    Accessories
    Remote control unit IR 38kHz NEC
    User Manual 1 in English
    RCA cable 1(Optional)
    HDMI Cable 1(Optional)
    Power
    DC INPUT 12V/1.5A(Optional)
    Power consumption Max 18W
    Physical
    Operating Temperature 0 ~ 45 °C
    Remarks:
    1. Delivery term: FOB Shenzhen
    2. Payment term: 30% deposit,balance T/T before shipment
    3. Lead time: 30 days after deposit
    4. One year warranty starts from ETA
    Taking into consideration that we (UMT LLC) are developer and system integrator, also do not stop on our technical growth and improvement, know that view of all our devices and equipment including their technical parameters may be different from pictures presented on website and parameters listed on each device webpage.  Note! All details customer has to confirm in advance during ordering and before payment. Those parameters that were not specified and / or were not agreed while ordering will be implemented as basic at the discretion of the manufacturer. Each our customer has 1.5 year warranty and 7 year aftersales support for whole range of our products.
