STB-UMT-ST265-mini

Short description

STB-UMT-ST265-mini is set-top box (STB, receiver, television decoder) which works in DVB-S, DVB-S2, DVB-T and DVB-T2 standards and supports MPEG-2/MPEG-4/H.264/HEVC/H.265 codecs, also has CA smart card slot.

- +

طلب معدات مخصصة HEAD-END

    • Description
    • Downloads
    Specification
    DVB-T2 Tuner
    InputFrequency Range VHF&UHF
    Demodulation COFDM(QPSK/QAM16/QAM64) ,Supports all five QAM modes: 16/32/64/128QAM, and 256 QAM
    Bandwidth Bandwidth 7,8
    RF output Connector (bypass)IEC 169-2 Male
    Loop through 177.5-226.5MHz(VHF),474-858 MHz(UHF)
    DVB-S2 Tuner
    InputFrequency 950 to 2150Mhz
    Input level -79 to-11dbm
    Symbol Rate 1 to 45M
    In put impedance 75
    DVB-S2 Demodulation
    Wave from 64/16/4QAM
    Demodulation QPSK,8PSK,16APSK,32APSK
     Rate 1/2,2/3,3/4,5/6,7/8,8/9,9/10
    System Resources
    SDRAM memory 1GBit
    FLASH memory 64MBit Flash
    Video Decoder
    Standard ISO/IEC 13818-2 and ISO/IEC 14496-10
    Transport stream ISO/IEC 13818-1
    Video decoding HEVC/H.265,MPEG-4 H.264/AVC SD/HD,MPEG-2 SD/HD (MP@ML and MP@HL),
    JPEG,BMP,PNG, Motion JPEG
    AVI, VOB, MOV, MKV
    Video Resolution 480i, 480p, 576i, 576p, 720p, 1080i, 1080p
    Aspect ratio 4:3, 16:9，Auto
    Audio Decoder
    Standard MPEG-1 ,MPEG-2(Layer I & II),MP3,AAC-LC 5.1, HE-AAC v1/v2,AC-3(optional), E-AC-3(optional)
    Sample rate 32, 44.1, 48
    Software
    EPG yes
    Teletext Support yes
     DVB Subtitle yes
    LCN Support (Nordig v1) yes
     Automatic NIT Search start with S21 (306 Mhz) yes
    Option to enable disable LCN support in the Menu yes
    FTE/Scrambled Channel Selection in the Menu yes
     OTA via Cable (DSM-CC) and USB No
     Fav List yes
    Multi Language User Interface incl. German, English, … yes
    Front Panel
    Led display yes(optional)
    bi-colored LED Red / Green to indicate the various states of the STB
    smart card No, One SmartCard Slot
    Front panel keyboard 3
    Infra-red receiver yes
    Rear Panel
    LNB  IN IEC169-2 Female
    ANT  IN ISO/IEC 13818-1
    Video& Audio R/L RCA
    USB USB2.0 interface*2pcs
    LAN 1
    Accessories
    Remote control unit IR 38kHz NEC
    Led display 1pcs
    User Manual 1 in English
    RCA cable 1(Optional)
    HDMI Cable 1(Optional)
    Power
    DC INPUT 12V/1A
    Power consumption Max 12W
    Physical
    Operating Temperature 0 ~ 45 °C
    Remarks:
    1. Delivery term: FOB Shenzhen
    2. Payment term: 30% deposit,balance T/T before shipment
    3. Lead time: 35 days after deposit
    4. One year warranty starts from ETA

    Taking into consideration that we (UMT LLC) are developer and system integrator, also do not stop on our technical growth and improvement, know that view of all our devices and equipment including their technical parameters may be different from pictures presented on website and parameters listed on each device webpage.
    Note! All details customer has to confirm in advance during ordering and before payment. Those parameters that were not specified and / or were not agreed while ordering will be implemented as basic at the discretion of the manufacturer. Each our customer has 1.5 year warranty and 7 year aftersales support for whole range of our products.
