LSA-KuV90 v1

LSA-KuV90 v1

LSA-KuV90 v1 is Long Sector Antenna.

It has:

► Light weight + Compact size + High gain

► Radiation pattern of 90 degrees and V-polarization

► Beam (H): 90°; Beam (V): 6°

► Frequency range: 10.7-13.5 GHz

► Gain: 18 dB

► It is designed for Ku-band

أكثر
LSA-KuH120

LSA-KuH120

LSA-KuH120 is Long Sector Antenna.

It has:

► Light weight + Compact size + High gain

► Radiation pattern of 120 degrees and H-polarization

► Beam(H):120°; Beam(V):12°

► Frequency range: 10.7-13.5 GHz

► Gain: 13 dB

► It is designed for Ku-band

أكثر
SSA-KuH180 v1

SSA-KuH180 v1

SSA-KuH180 is Short Sector Antenna.

It has:

► Light weight + Compact size + High gain

► Radiation pattern of 180 degrees and H-polarization

► Beam(H):180°; Beam(V):16°

► Frequency range: 10.7-13.5 GHz

► Gain: 9 dB

► It is designed for Ku-band

أكثر
HPSA-DP

HPSA-DP

HPSA-DP is Horn Parabolic Sector Dual Polarization Antenna.

► Light weight + Compact size + High gain + supports two polarizations

► Gain: 15.8-17.9 dBi

► It is designed for Ku-band (full range)

► Frequency range of 10-15 GHz

► Dual-polarization

► Beam (H): 56.8-76.5°; Beam (V): 5.6-8°

أكثر
LSA-KuH120 v2

LSA-KuH120 v2

LSA-KuH120 v2 v2 is Long Sector Antenna.

It has:

► Light weight + Compact size + High gain

► Radiation pattern of 120 degrees and H-polarization

► Beam (H): 120°; Beam (V): 12°

► Frequency range: 11-13.5 GHz

► Gain: 14 dB

► It is designed for Ku-band

أكثر
PAA-KuDP110

PAA-KuDP110

PAA-KuDP110 is PAA-KuDP110 is Phased Array Antenna.

It has:

► Light weight + Compact size + High gain

► Radiation pattern of 110 degrees and DUAL polarization

► Beam(H): 110°; Beam (V): 35°

► Frequency range: 8-12 GHz

► Gain: 10 dB

► It is designed for Ku-band

أكثر
BOA-Ku04

BOA-Ku04

BOA-Ku04 is omni antenna of “Barrel” type

► It is designed for Ku-band (or for C-band – optional) with 360° radiation pattern and linear polarization

► Frequency range of 10-14 GHz

► Beam (H): 360°; Beam (V): 8°

► Gain: 10 dB

أكثر
SWA-Ku360 v2 12.7-13.5 GHz

SWA-Ku360 v2 12.7-13.5 GHz

SWA-Ku360 v2 12.7-13.5 GHz is omni Slotted Waveguide Antenna

► It is designed for Ku-band with antenna aperture of 360° and linear polarization

► Frequency range of 12.7-13.5 GHz (or any 800MHz of Ku-band)

► Beam (H): 360°; Beam (V): 10°

► Gain: 11 dBi

أكثر
SWA-Ku360 v2 10.7-11.7 GHz

SWA-Ku360 v2 10.7-11.7 GHz

SWA-Ku360v2 10.7-11.7 GHz is omni Slotted Waveguide Antenna

► It is designed for Ku-band with antenna aperture of 360° and H-polarization

► Frequency range of 10.7-11.7 GHz (or other 800 MHz of Ku-band)

► Beam (H): 360°; Beam (V): 10°

► Gain: 11 dBi

أكثر
SWA-Ku360 v2 11.7-12.7 GHz

SWA-Ku360 v2 11.7-12.7 GHz

SWA-Ku360v2 11.7-12.7 GHz is omni Slotted Waveguide Antenna

► It is designed for Ku-band with antenna aperture of 360° and H-polarization

► Frequency range of 11.7-12.7 GHz (or other 800 MHz of Ku-band)

► Beam (H): 360°; Beam (V): 10°

► Gain: 11 dBi

أكثر
OLSAA-KuH2

OLSAA-KuH2

OLSAA-KuH2 is Omni Long Sector Antenna Assembly

► It is designed for Ku-band (full range!) with antenna aperture of 360° and linear polarization

► Frequency range of 10.7-13.6 GHz

► Beam (H): 360°; Beam (V): 12°

► Gain: 10 dBi

أكثر
SWA-Ku360 v2 13.75-14.5 GHz

SWA-Ku360 v2 13.75-14.5 GHz

SWA-Ku360 v2 13.75-14.5 GHz is omni Slotted Waveguide Antenna

► It is designed for Ku-band with antenna aperture of 360° and linear polarization

► Frequency range of 13.75-14.5 GHz (or any 800MHz of Ku-band)

► Beam (H): 360°; Beam (V): 10°

► Gain: 11 dBi

أكثر
HPSA-KuH120

HPSA-KuH120

HPSA-KuH120 is Horn Parabolic Sector Antenna.

► Light weight + Compact size + High gain

► Gain: 17 dBi

► It is designed for Ku-band (full range)

► Frequency range of 10-15 GHz

► Radiation pattern of 120° and H-polarization

► Beam (H): 120°; Beam (V): 8°

أكثر
BOA-Ku06

BOA-Ku06

BOA-Ku06 is omni antenna of “Barrel” type

► It is designed for Ku-band (or for C-band – optional) with 360° radiation pattern and linear polarization

► Frequency range of 10-14 GHz

► Beam (H): 360°; Beam (V): 6°

► Gain: 13 dB

أكثر
OHPSA-KuH2

OHPSA-KuH2

OHPSA-KuH2 is Omni Horn Parabolic Sector Antenna

► It is designed for Ku-band (full range!) with antenna aperture of 360° and linear polarization

► Frequency range of 10-15 GHz

► Beam (H): 360°; Beam (V): 6°

► Gain: 13 dBi





أكثر
BOA-Ku09

BOA-Ku09

BOA-Ku09 is omni antenna of “Barrel” type

► It is designed for Ku-band (or for C-band – optional) with 360° radiation pattern and linear polarization

► Frequency range of 10-14 GHz

► Beam (H): 360°; Beam (V): 4°

► Gain: 16 dB







أكثر
BiOA-X/Ku-360

BiOA-X/Ku-360

BiOA-X/Ku-360 is biconic omni antenna



► It is designed for Ku band with antenna aperture of 360° and linear polarization

► Frequency range of 8.0-18.0 GHz

► Beam (H): 360°; Beam (V): 8°

► Gain: 8 dBi

► Full X and Ku-band covering

أكثر
SSA-KuV90

SSA-KuV90

SSA-KuV90 is Short Sector Antenna.

It has:

► Light weight + Compact size + High gain

► Radiation pattern of 90 degrees and V-polarization

► Beam(H): 90°; Beam (V): 20°

► Frequency range: 10.7-13.5GHz

► Gain: 13 dB

► It is designed for Ku-band

أكثر
SSA-KuH180 v2

SSA-KuH180 v2

SSA-KuH180 v2 is Short Sector Antenna.

It has:

► Light weight + Compact size + High gain

► Radiation pattern of 180 degrees and H-polarization

► Beam(H):180°; Beam(V):16°

► Frequency range: 10.5-13.5 GHz

► Gain: 11.5-12.5 dB

► It is designed for Ku-band

أكثر
LSA-KuV90 v2

LSA-KuV90 v2

LSA-KuV90 v2 is Long Sector Antenna.

It has:

► Light weight + Compact size + High gain

► Radiation pattern of 90 degrees and V-polarization

► Beam (H): 90°; Beam (V): 6°

► Frequency range: 10.7-13.5 GHz

► Gain: 18 dB

► It is designed for Ku-band

أكثر
SSA-KuV180

SSA-KuV180

SSA-KuV180 is Short Sector Antenna.

It has:

► Light weight + Compact size + High gain

► Radiation pattern of 180 degrees and V-polarization

► Beam(H):180°; Beam(V):15°

► Frequency range: 10.7-14.4 GHz

► Gain: 10.6 dB

► It is designed for Ku-band

أكثر
RCPOA 8-18 GHz

RCPOA 8-18 GHz

RCPOA 8-18 GHz is Reflective Conical Parabolic Omni Antenna which receives ALL polarizations: vertical V / horizontal H / right-hand circular RHCP / left-hand circular LHCP / elliptical

► It is designed for both X + Ku bands

► Has 360° radiation pattern

► Supports ALL polarizations

► Wide frequency range of 8-18 GHz

أكثر
