DVB-IP 10-ASI Streamer

Brève description

Developed for television content broadcasting in IPTV networks. DVB-IP Streamer has up to 10 ASI inputs and supports up to 256 output IP streams (640 Mbit/s), has great performance and user-friendly management interface.

- +

Demande d'équipement sur mesure HEAD-END

    • Description
    • Téléchargements
    Specification
    INPUT 10xASI TS, up to 150 Mbit/s each port, BNC interface, 75 Ohm;
    Packet length 188/204
    Mode  packet, byte, automatic determination;
    OUTPUT  up to 256 IP streams, 640 Mbit/s, 10/100/1000Base-T Ethernet Interface, RJ-45;
    Packet length:  188/204
    Mode packet, byte
    Stream type UDP or RTP, Unicast or Multicast, VBR or CBR;
    Features IP FEC (SMPTE2022/(COP3R2)), IGMP v1, v2, v3;
    Bitrate measurement interval 1 sec – 1 week;
    System function  LCD & Key board control (option), web NMS management (1×10/100 BaseT Ethernet), Ethernet software upgrade;
    Power 220V±10%,50/60Hz;
    Power Consumption 20W max;
    Operation temperature range  0℃…+45℃
    Dimensions  19”, 1RU 482×240×44 (WxDxH) (mm);
    Weight  3.5 kg

    Taking into consideration that we (UMT LLC) are developer and system integrator, also do not stop on our technical growth and improvement, know that view of all our devices and equipment including their technical parameters may be different from pictures presented on website and parameters listed on each device webpage.
    Note! All details customer has to confirm in advance during ordering and before payment. Those parameters that were not specified and / or were not agreed while ordering will be implemented as basic at the discretion of the manufacturer. Each our customer has 1.5 year warranty and 7 year aftersales support for whole range of our products.

    Documentation
