Antennes sectorielles

Les antennes sectorielles ont un diagramme de rayonnement en forme de secteur : un énorme diagramme horizontal et moins vertical. Un tel principe permet de couvrir exactement la zone d’un secteur long

Antennes Dirigées

Antennes Dirigées

Antennes Omni

Antennes Omni


Ajouter un filtre

Filters

Polarization

Frequency band

Radiation patter in H-plane

LSA-KuV90 v1

LSA-KuV90 v1

LSA-KuV90 v1 is Long Sector Antenna.

It has:

► Light weight + Compact size + High gain

► Radiation pattern of 90 degrees and V-polarization

► Beam (H): 90°; Beam (V): 6°

► Frequency range: 10.7-13.5 GHz

► Gain: 18 dB

► It is designed for Ku-band

Plus
LSA-KuH120

LSA-KuH120

LSA-KuH120 is Long Sector Antenna.

It has:

► Light weight + Compact size + High gain

► Radiation pattern of 120 degrees and H-polarization

► Beam(H):120°; Beam(V):12°

► Frequency range: 10.7-13.5 GHz

► Gain: 13 dB

► It is designed for Ku-band

Plus
SSA-KuH180 v1

SSA-KuH180 v1

SSA-KuH180 is Short Sector Antenna.

It has:

► Light weight + Compact size + High gain

► Radiation pattern of 180 degrees and H-polarization

► Beam(H):180°; Beam(V):16°

► Frequency range: 10.7-13.5 GHz

► Gain: 9 dB

► It is designed for Ku-band

Plus
HPSA-DP

HPSA-DP

HPSA-DP is Horn Parabolic Sector Dual Polarization Antenna.

► Light weight + Compact size + High gain + supports two polarizations

► Gain: 15.8-17.9 dBi

► It is designed for Ku-band (full range)

► Frequency range of 10-15 GHz

► Dual-polarization

► Beam (H): 56.8-76.5°; Beam (V): 5.6-8°

Plus
SSA-CV70 v1

SSA-CV70 v1

SSA-CV70 is Short Sector Antenna.

It has:

► Light weight + Compact size + High gain

► Radiation pattern of 70 degrees and V-polarization

► Beam(H): 70°; Beam(V): 24°

► Frequency range: 3 – 5 GHz

► Gain: 13 dB

► It is designed for C-band

Plus
LSA-KuH120 v2

LSA-KuH120 v2

LSA-KuH120 v2 v2 is Long Sector Antenna.

It has:

► Light weight + Compact size + High gain

► Radiation pattern of 120 degrees and H-polarization

► Beam (H): 120°; Beam (V): 12°

► Frequency range: 11-13.5 GHz

► Gain: 14 dB

► It is designed for Ku-band

Plus
SSA-XV70 v1

SSA-XV70 v1

SSA-XV70 v1 is Short Sector Antenna.

It has:

► Light weight + Compact size + High gain

► Radiation pattern of 70 degrees and V-polarization

► Beam(H): 70°; Beam(V): 29°

► Frequency range: 8 – 12 GHz

► Gain: 12.2 dB

► It is designed for X-band

Plus
PAA-KuDP110

PAA-KuDP110

PAA-KuDP110 is PAA-KuDP110 is Phased Array Antenna.

It has:

► Light weight + Compact size + High gain

► Radiation pattern of 110 degrees and DUAL polarization

► Beam(H): 110°; Beam (V): 35°

► Frequency range: 8-12 GHz

► Gain: 10 dB

► It is designed for Ku-band

Plus
HPSA-KuH120

HPSA-KuH120

HPSA-KuH120 is Horn Parabolic Sector Antenna.

► Light weight + Compact size + High gain

► Gain: 17 dBi

► It is designed for Ku-band (full range)

► Frequency range of 10-15 GHz

► Radiation pattern of 120° and H-polarization

► Beam (H): 120°; Beam (V): 8°

Plus
SSA-CV60

SSA-CV60

SSA-CV60 is Short Sector Antenna.

It has:

► Light weight + Compact size + High gain

► Radiation pattern of 60 degrees and V-polarization

► Beam(H): 60°; Beam(V): 20°

► Frequency range: 3.94 – 5.99 GHz

► Gain: 10 dB

► It is designed for C-band

Plus
SSA-KuV90

SSA-KuV90

SSA-KuV90 is Short Sector Antenna.

It has:

► Light weight + Compact size + High gain

► Radiation pattern of 90 degrees and V-polarization

► Beam(H): 90°; Beam (V): 20°

► Frequency range: 10.7-13.5GHz

► Gain: 13 dB

► It is designed for Ku-band

Plus
SSA-KuH180 v2

SSA-KuH180 v2

SSA-KuH180 v2 is Short Sector Antenna.

It has:

► Light weight + Compact size + High gain

► Radiation pattern of 180 degrees and H-polarization

► Beam(H):180°; Beam(V):16°

► Frequency range: 10.5-13.5 GHz

► Gain: 11.5-12.5 dB

► It is designed for Ku-band

Plus
LSA-KuV90 v2

LSA-KuV90 v2

LSA-KuV90 v2 is Long Sector Antenna.

It has:

► Light weight + Compact size + High gain

► Radiation pattern of 90 degrees and V-polarization

► Beam (H): 90°; Beam (V): 6°

► Frequency range: 10.7-13.5 GHz

► Gain: 18 dB

► It is designed for Ku-band

Plus
SSA-KuV180

SSA-KuV180

SSA-KuV180 is Short Sector Antenna.

It has:

► Light weight + Compact size + High gain

► Radiation pattern of 180 degrees and V-polarization

► Beam(H):180°; Beam(V):15°

► Frequency range: 10.7-14.4 GHz

► Gain: 10.6 dB

► It is designed for Ku-band

Plus
LSA-KH120

LSA-KH120

LSA-KH120 is Long Sector Antenna designed for K-band.

► Light weight + Compact size + High gain

► Gain: 15 dBi

► It is designed for K-band

► Frequency range of 18-26 GHz

► Radiation pattern of 120° and H-polarization

► Beam (H): 120°; Beam (V): 6°

Plus
Antenne sectorielle personnalisée

Antenne sectorielle personnalisée

3 étapes faciles pour obtenir un développement spécial de notre société :

1. Cliquez sur le bouton “demande/personnalisé”.

2. Remplissez les paramètres nécessaires.

3. Attendez notre réponse.

P.S. Nous vous répondrons dès que possible après le traitement de la requête conformément à nos heures d’ouverture.
