LNB PLL LO 11.80

LNB PLL LO 11.80

Ku-band LNB PLL LO 11.80 is Low Noise Block Down Converter with single LO 11.80 GHz and single 75 Ohm F-type output. LO instability: ± 150 kHz, Gain: 45 dB, Noise figure: 0.9 dB, Output power P1dB: +3 dBm.

Plus
BUC-Ku20-11.8 v1.5

BUC-Ku20-11.8 v1.5

BUC-Ku20-11.8-v.2 is block up-converter with fixed output power P1dB 20 W (ALC power: 2000 mW) and LO of 11.8 GHz.

Our BUC operates with up to 25 carriers and has built-in reference of 10 MHz;

and ALC with 25 dB range;

+ LED status indication at the rear side.

Plus
BUC-Ku20-11.8

BUC-Ku20-11.8

BUC-Ku20-11.8 is block up-converter with fixed output power P1dB 20 W (ALC power: 2000 mW) and LO of 11.8 GHz.

Our BUC operates with up to 25 carriers and has built-in reference of 10 MHz;

and ALC with 25 dB range;

+ LED status indication at the rear side.

Plus
BUC-Ku04-11.8

BUC-Ku04-11.8

BUC-Ku04-11.8 is block up-converter with fixed output power P1dB 4 W (ALC power: 400 mW) and LO of 11.8 GHz.

Our BUC operates with up to 25 carriers and has built-in reference of 10 MHz;

and ALC with 25 dB range;

+ LED status indication at the rear side.

Plus
BUC-Ku02-11.8

BUC-Ku02-11.8

BUC-Ku02-11.8 is block up-converter with fixed output power P1dB 2 W (ALC power: 200 mW) and LO of 11.8 GHz.

Our BUC operates with up to 25 carriers and has built-in reference of 10 MHz;

and ALC with 25 dB range;

+ LED status indication at the rear side.

Plus
BUC-Ku01-11.8

BUC-Ku01-11.8

BUC-Ku01-11.8 is block up-converter with fixed output power P1dB 1 W (ALC power: 100 mW) and LO of 11.8 GHz.

Our BUC operates with up to 25 carriers and has built-in reference of 10 MHz;

has ALC with 25 dB range;

+ LED status indication at the rear side.

Plus
BUC-Ku002-11.8

BUC-Ku002-11.8

BUC-Ku002-11.8 is block up-converter with fixed output power P1dB 0.2 W (ALC power: 30 mW) and LO of 11.8GHz.

Our BUC operates with up to 25 carriers and has built-in reference of 10 MHz;

has ALC with 25 dB range;

+ LED status indication at the rear side.

Plus
LNB PLL with AGC LO 11.80

LNB PLL with AGC LO 11.80

Ku-band LNB PLL with AGC LO 11.80 is low noise block down converter with automatic gain control. It is professional LNB with wide dynamic range – up to 50 dB (biggest among any other LNB). AGC range: 20 dB, LO instability: ±25 kHz, Gain (min): 34 dB.

Plus
LNB DRO LO 11.80

LNB DRO LO 11.80

Ku-band LNB DRO LO 11.80 is Low Noise Block Down Converter with single LO 11.80 GHz and single 75 Ohm F-type output. LO instability: ± 2 MHz, Gain: 58 dB, Noise figure: 0.9 dB, Output power P1dB: +3 dBm.

Plus
PLL LNB with AGC L.O. 11.8

PLL LNB with AGC L.O. 11.8

PLL LNB with AGC L.O. 11.8 is professional low noise block down converter with automatic gain control, wide dynamic range of up to 50 dB (biggest among any other LNB). AGC range of 25 dB, LO instability of 50 kHz, Gain (min) of 40 dB.

Plus
