Ku-Band Low noise block downconverter (LNB)
Seeking top-notch Ku-band low noise block converters (LNBs) for your satellite setup? Look no further than UMT LLC’s exceptional range of Ku-Band LNBs designed to optimize your satellite reception.
Receivers and Converters for TV Stations, TV Links, VSAT, DSNG and Satellite Reception Systems
Covering the main Ku-band satellite downlink range with LO options from 8.8 to 13.05 GHz, UMT Ku-band LNB are designed for stable professional signal reception, frequency conversion and long-term 24/7 operation. Available with PLL or DRO oscillator options, low noise figure, high conversion gain, AGC versions and 50 Ohm or 75 Ohm output interfaces, these LNB provide reliable compatibility with broadcast, telecom, VSAT and satellite TV receiving systems. Designed for satellite TV reception, TV head-end systems, TV links, repeater stations, VSAT terminals, DSNG and professional monitoring applications.
C-Band LNB
K-Band LNB
KA-Band LNB
X-Band LNB
Filters
Customized Ku-band LNB
3 easy steps to obtain special development from our company:
1. Click button “request/сustomized”.
2. Fill needed parameters.
3. Wait for our reply.
P.S. We will reply you as soon as possible after query processing in accordance to our business hours.
LNB PLL LO 8.80
Ku-band LNB PLL LO 8.80 is Low Noise Block Down Converter with single LO 8.80 GHz and single 75 Ohm F-type output. LO instability: ± 150 kHz, Gain: 45 dB, Noise figure: 0.9 dB, Output power P1dB: +3 dBm.
LNB PLL LO 9.75
Ku-band LNB PLL LO 9.75 is Low Noise Block Down Converter with single LO 9.75 GHz and single 75 Ohm F-type output. LO instability: ± 150 kHz, Gain: 45 dB, Noise figure: 0.9 dB, Output power P1dB: +3 dBm.
LNB PLL dual LO: 9.75 + 10.60 v.2
Ku-band LNB PLL dual LO 9.75 10.6 v.2 is Low Noise Block Down Converter with dual local oscillator 9.75 GHz and 10.6 GHz and dual 50 Ohm N-type output. LO instability: ± 2.5 ppm, Gain: 55 dB, Noise figure: 0.8 dB, Output power P1dB: 0 dBm.
LNB PLL LO 10.60
Ku-band LNB PLL LO 10.60 is Low Noise Block Down Converter with single LO 10.60 GHz and single 75 Ohm F-type output. LO instability: ± 150 kHz, Gain: 45 dB, Noise figure: 0.9 dB, Output power P1dB: +3 dBm.
LNB PLL LO 10.75
Ku-band LNB PLL LO 10.75 is Low Noise Block Down Converter with single LO 10.75 GHz and single 75 Ohm F-type output. LO instability: ± 150 kHz, Gain: 45 dB, Noise figure: 0.9 dB, Output power P1dB: +3 dBm.
LNB PLL LO 11.30
Ku-band LNB PLL LO 11.30 is Low Noise Block Down Converter with single LO 11.30 GHz and single 75 Ohm F-type output. LO instability: ± 150 kHz, Gain: 45 dB, Noise figure: 0.9 dB, Output power P1dB: +3 dBm.
LNB PLL LO 11.80
Ku-band LNB PLL LO 11.80 is Low Noise Block Down Converter with single LO 11.80 GHz and single 75 Ohm F-type output. LO instability: ± 150 kHz, Gain: 45 dB, Noise figure: 0.9 dB, Output power P1dB: +3 dBm.
LNB PLL LO 12.80
Ku-band LNB PLL LO 12.80 is Low Noise Block Down Converter with single LO 12.80 GHz and single 75 Ohm F-type output. LO instability: ± 150 kHz, Gain: 45 dB, Noise figure: 0.9 dB, Output power P1dB: +3 dBm.
Advantages of buying Ku-Band low noise block converters (LNBs) from UMT LLC ?
When you opt for UMT LLC’s Ku-Band LNBs, you benefit from:
- High-quality products with extended durability and performance standards
- Competitive prices and special offers for Ku-Band LNBs
- Global delivery options, reaching the USA, India, Europe, Africa, and beyond
- Comprehensive catalog showcasing various Ku-Band LNB types and specifications
- Tailored solutions for specific satellite frequency bands and reception requirements
- Exceptional customer support and detailed product specifications to guide your purchase decisions
- Universal bracket modifications to fit diverse dish setups
- Enhanced digital signal reception for an immersive viewing experience
Whether you require a standard Ku-Band LNB or a modified receiver, UMT LLC is your trustworthy source for all things Ku-Band LNB-related, delivering superior performance and quality across the board.
Why do you need to buy Ku-Band LNB for TV Stations, TV Links, VSAT and Satellite Reception Systems from UMT LLC?
Looking for a reliable Ku-band LNB for your TV head-end, satellite receiving station, TV link, VSAT terminal or professional monitoring system? UMT LLC offers a full range of Ku-band Low Noise Block Downconverters tailored for B2B satellite communication networks, TV broadcasting, DVB reception, DSNG and teleport applications.
Discover professional Ku-band LNB from UMT LLC for your satellite receiving systems:
- for TV head-end,
- for TV link,
- for TV repeater,
- for satellite reception systems,
- VSAT,
- DSNG,
- DVB-S/S2/S2X reception,
- monitoring and measurement stations, etc.
Our Ku-band LNB are designed for stable signal reception according to the needs of your TV and satellite business, delivering low-noise performance, frequency stability and reliable operation in demanding professional environments.
Key Advantages of Professional Ku-Band LNB from UMT LLC
Low-Noise Ku-band LNB for Professional Satellite Reception
UMT Ku-band LNB are engineered for clean and stable reception of satellite signals before downconversion to the L-band IF range. Low noise figure, stable gain and reliable oscillator performance help preserve signal quality for DVB-S, DVB-S2, DVB-S2X, VSAT and broadcast receiving systems.
Wide Frequency Range & L.O. Options
Our Ku-band LNB support a broad selection of local oscillator frequencies, including 8.8 GHz, 9.75 GHz, 10.6 GHz, 10.75 GHz, 11.3 GHz, 11.8 GHz, 12.8 GHz, 13.05 GHz and dual LO options. This allows integration with different satellite transponders, frequency plans and receiving architectures across Europe, Africa, the Middle East, Asia and other regions.
PLL and DRO Oscillator Options
Choose PLL LNB when high frequency stability and low phase noise are required for professional digital reception, narrowband carriers, DVB-S2/S2X and demanding satellite links. DRO LNB options are available for standard applications where simple and cost-effective Ku-band reception is required.
Stable Gain, AGC Options and Reliable IF Output
UMT Ku-band LNB are available with stable conversion gain, low noise figure and AGC automatic gain control options for improved signal handling in systems with variable input levels. Depending on the model, output interfaces can include F-type 75 Ohm, N-type 50 Ohm or customized connector options for smooth integration with receivers, IRD, modulators, analyzers and professional head-end equipment.
Seamless Integration & Compatibility
Our Low Noise Block Downconverters are compatible with standard satellite receiving chains, including parabolic antennas, feed systems, waveguide interfaces, coaxial IF distribution, L-band receivers, DVB IRD and monitoring equipment. UMT can also provide customized LNB configurations according to your input frequency range, LO frequency, LO instability, gain, output frequency range and connector requirements.
Rugged Design for 24/7 Operation
Professional Ku-band LNB from UMT LLC are designed for continuous operation in real receiving stations, remote sites and outdoor satellite systems. They are suitable for long-term use in broadcast networks, telecom infrastructure, TV repeater systems, DSNG vehicles, VSAT installations and critical signal receiving applications.
Applications Across Industries
UMT LLC designs, develops and supplies Ku-band LNB for TV broadcasters, satellite operators, telecom providers, DVB network integrators, system installers and professional RF engineers. Whether you need a standard Ku-band LNB, a PLL LNB with improved stability, a dual LO model, an AGC version or a custom downconverter, UMT offers solutions tailored to professional satellite reception tasks.
Competitive Prices, Global Delivery
We deliver professional Ku-band LNB worldwide at competitive pricing. Whether you need a PLL Ku-band LNB, a low noise block downconverter for broadcast reception, a dual LO LNB, an AGC LNB or a customized receiving solution for your satellite system, UMT LLC provides reliable equipment, technical support and fast international supply.
Whether you need a Ku-band PLL LNB with LO 9.75 GHz, a 10.6 GHz LNB for standard satellite reception, a dual LO 9.75 + 10.6 GHz model or a customized LNB with specific gain, noise figure and output interface, UMT offers reliable and cost-effective solutions for 24/7/365 B2B requirements.
