SSPB C-band
Professional range of high‑power SSPB C‑band amplifiers
designed for business applications. Offering output frequencies from 5.725–6.425 GHz, power levels up to 1000W and superior gain with low phase noise, these solid‑state solutions ensure reliable performance for VSAT hubs, teleports, gateways, and broadcast uplinks. Benefit from efficient cooling, 24/7 support and trusted quality to strengthen your satellite infrastructure
Order in our store
C-band BUC
Ku-band BUC
K-band BUC
Ka-band BUC
Repeater Blocks
Filters
C-band SSPB 100W 5.725-6.425 GHz Solid State Power BUC
High power C-band SSPB 100W, out freq. 5.725-6.425 GHz, 70 dB gain, low phase noise, linear design with forced air cooling. Ideal for VSAT hubs, gateways and broadcast satcom. Psat 51.7 dBm, LO 4.75 GHz, IF range 975-1675 MHz
C-band SSPB 100W 5.85-6.425 GHz Solid State Power BUC
High power C-band SSPB 100W, out freq. 5.85-6.425 GHz, 70 dB gain, low phase noise, linear design with forced air cooling. Ideal for VSAT hubs, gateways and broadcast satcom. Psat 51.7 dBm, LO 4.90 GHz, IF range 975-1525 MHz
C-band SSPB 100W 5.85-6.725 GHz Solid State Power BUC
High power C-band SSPB 100W, out freq. 5.85-6.725 GHz, 70 dB gain, low phase noise, linear design with forced air cooling. Ideal for VSAT hubs, gateways and broadcast satcom. Psat 51.7 dBm, LO 4.90 GHz, IF range 975-1825 MHz
C-band SSPB 200W 5.85–6.425 GHz Solid State Power BUC
High-power C-band SSPB 200W, out freq. 5.85–6.425 GHz, 70 dB gain, low phase noise, and solid-state linear design. Ideal for VSAT hubs, gateways, and broadcast satcom uplinks. Psat 53 dBm, LO 4.9 GHz, IF range 950–1525 MHz.
C-band SSPB 200W 5.725–6.425 GHz Solid State Power BUC
High-power C-band SSPB 200W, out freq. 5.725–6.425 GHz, 70 dB gain, low phase noise, and solid-state linear design. Ideal for VSAT hubs, gateways, and broadcast satcom uplinks. Psat 53 dBm, LO 4.75 GHz, IF range 950–1675 MHz.
C-band SSPB 200W 5.85–6.725 GHz Solid State Power BUC
High-power C-band SSPB 200W, out freq. 5.85–6.725 GHz, 70 dB gain, low phase noise, and solid-state linear design. Ideal for VSAT hubs, gateways, and broadcast satcom uplinks. Psat 53 dBm, LO 4.9 GHz, IF range 950–1825 MHz.
C-band SSPB 250W 5.85–6.425 GHz Solid State Power BUC
High-power C-band SSPB 250W, out freq. 5.85–6.425 GHz, 70 dB gain, low phase noise, and solid-state linear design. Ideal for VSAT hubs, gateways, and broadcast satcom uplinks. Psat 53 dBm, LO 4.9 GHz, IF range 950–1525 MHz.
C-band SSPB 250W 5.85–6.725 GHz Solid State Power BUC
High-power C-band SSPB 250W, out freq. 5.85–6.725 GHz, 70 dB gain, low phase noise, and solid-state linear design. Ideal for VSAT hubs, gateways, and broadcast satcom uplinks. Psat 53 dBm, LO 4.9 GHz, IF range 950–1825 MHz.
C-band SSPB 250W 5.725–6.425 GHz Solid State Power BUC
High-power C-band SSPB 250W, out freq. 5.725–6.425 GHz, 70 dB gain, low phase noise, and solid-state linear design. Ideal for VSAT hubs, gateways, and broadcast satcom uplinks. Psat 53 dBm, LO 4.75 GHz, IF range 950–1675 MHz.
