SSA-KuV180
SSA-KuV180 is Short Sector Antenna.
It has:
► Light weight + Compact size + High gain
► Radiation pattern of 180 degrees and V-polarization
► Beam(H):180°; Beam(V):15°
► Frequency range: 10.7-14.4 GHz
► Gain: 10.6 dB
► It is designed for Ku-band
SSA-KuH180 v2
SSA-KuH180 v2 is Short Sector Antenna.
It has:
► Light weight + Compact size + High gain
► Radiation pattern of 180 degrees and H-polarization
► Beam(H):180°; Beam(V):16°
► Frequency range: 10.5-13.5 GHz
► Gain: 11.5-12.5 dB
► It is designed for Ku-band
Customized Sector Antenna
3 easy steps to obtain special development from our company:
1. Click button “request/сustomized”.
2. Fill needed parameters.
3. Wait for our reply.
P.S. We will reply you as soon as possible after query processing in accordance to our business hours.
SSA-KuH180 v1
SSA-KuH180 is Short Sector Antenna.
It has:
► Light weight + Compact size + High gain
► Radiation pattern of 180 degrees and H-polarization
► Beam(H):180°; Beam(V):16°
► Frequency range: 10.7-13.5 GHz
► Gain: 9 dB
► It is designed for Ku-band
