8-HD Encoder

Short description

8-HD Encoder is professional HD audio / video encoding and multiplexing device with integrated ASI input and outputs. 8 HDMI inputs support MPEG-4 AVC / H.264 / H.265 standards. 8-HD Encoder can be used both for IP TV (IP output MPTS / SPTS) and as a part of head-end station.

Out of production
- +
  • Description
  • Downloads

The 8-HD Encoder is applied for professional digital TV broadcasting: can be used both as independent device for IP TV and as a part of head-end station. 8-HD Encoder encodes HD audio & video channels and can multiplex them with 1 ASI stream (TS) for further transmitting. 8-HD Encoder has 8 HDMI inputs and both IP and ASI outputs. 8 HDMI inputs support MPEG-4 AVC/H.264 High Profile & Main Profile/H.265. Multiplexing the ASI TS and 8 encoded SPTS 8-HD Encoder generates MPTS IP/ASI streams with the inserted PSI/SI information.

KEY FEATURES:

  • 8 HDMI input + 1 ASI input
  • Supports MPEG-4 AVC/H.264 High Profile & Main Profile/H.265
  • Supports MPEG1 Layer 2 (HE-AAC (V2) or LC-AAC optional) audio encoding
  • TS multiplexing with auto-generated PSI/SI
  • Supports VBR/CBR video encoding
  • Supports 720P, 1080I, 1080P HD video format
  • MPTS or 8 SPTS ASI and IP outputs
  • IP null packet filter
  • PID filter and transparent transport
  • Real-time output bitrate monitoring
  • LCD + keyboard on the front panel + web management user interface
Digital video & audio input
Number of inputs, connector type 8 x HDMI (Type A receptacle)
ASI transport stream input
Number of inputs, connector type 1 x ASI input
Standard and data format DVB‐ASI
ASI TS multiplexing output
Number of outputs, connector type 2 x ASI, BNC female, 75Ω
tandard and data format DVB‐ASI
PSI processing PAT, PMT, NIT Insertion
Video encoding
Encoding format MPEG‐4 AVC/H.264: HP@L4.0
Resolution and frame rate 1920x1080p/i@60/50 fps, 1280x720p/i@50/60 fps, 720x576i@50/60 fps
Aspect ratio 1:1, 4:3 or 16:9
Video encoding rate and mode 0.8 to 19 Mbps each channel, CBR, VBR
Video processing De-interlacing, noise reduction, sharpening
Audio encoding
Encoding standards MPEG-1 Layer 2, HE-AAC (V2), LC-AAC
Audio mode Stereo or Mono
Audio sample rate 48 kHz
Audio encoding rate 64 to 384 kbps
Network management
Interface and connector type 1 x 100/1000 Base‐T Ethernet,  RJ‐45
Management Web-interface
Miscellaneous
Front panel LCD with 7 control buttons, 10 x dual color LED for status indications of power, work and alarm
Rear panel 1 x Power supply receptacle (AC Input),  1 x Power switch
Power supply
Input Voltage 110‐240 VAC, 50/60Hz
Power Consumption 25W (max)
Environmental
Operating Temperature 0℃ to 45℃ (32℉ to 113℉)
Storage Temperature ‐20℃ to 80℃ (‐4℉ to 176℉)
Operating Humidity 90%, non‐condensing
Mechanical
Dimensions  (W x H x D) 1RU: 440mm x 44.5mm x 410mm, 17.3’’ x 1.73’’ (1RU) x 16.1’’
Weight 4Kg (8.8 lbs)

Taking into consideration that we (UMT LLC) are developer and system integrator, also do not stop on our technical growth and improvement, know that view of all our devices and equipment including their technical parameters may be different from pictures presented on website and parameters listed on each device webpage.
Note! All details customer has to confirm in advance during ordering and before payment. Those parameters that were not specified and / or were not agreed while ordering will be implemented as basic at the discretion of the manufacturer. Each our customer has 1.5 year warranty and 7 year aftersales support for whole range of our products.
